5V 700mA 3.5W AC-DC Step Down Isolated Switching Power Supply Module
- $5.99
- Ex Tax: $5.99
- Product Code: trd026
- Availability: In Stock
Product Description
5V 700mA 3.5W AC-DC Step Down Isolated Switching Power Supply Module
Feature:
Item | Unit | Minimum | Typical values | Maximum | Test Conditions |
Input voltage range | V ac | 85 | 110/220 | 265 | Under full load condition |
| Input voltage range | V dc | 100 | 150/300 | 370 | |
Input Current | A | 0.0273(AC110V) 0.014(AC220V) | Under full load condition | ||
Input inrush current | A | 20 | Under full load condition | ||
The output voltage | Minimum current | Maximum current | Peak current | Output voltage range | Ripple |
+5V | 0A | 700mA | 800mA | 4.80~5.2V | 60mV |
Package included:
1 x 5V 700mA 3.5W AC-DC Step Down Isolated Switching Power Supply Module
